Roller shutters are available in a variety of materials. As a professional roller shutter company, Xinyi offers a comprehensive range of roller shutters in different materials such as PVC, aluminum, steel and acrylic. Our range of aluminum roller shutters and thermal shutters are made of sandwich panels and gaskets, providing excellent thermal insulation even in the most demanding environments.
| Product Information | |
| Product Name | Aluminum Roll Up Door |
| Door Panel | The thickness of Aluminum is 1.5 mm |
| Anodized surface | |
| Polyurethane (without CFC) | |
| Vertical track | Aluminium |
| Available Colors | Gray, white, red, beige, etc |
| Drive Voltage | Photocell Sensor/Safety edge bottom |
| Motor Option | German SEW & Nord/China SEJ Size from 0.75JW – 2.2 KW accordingly to different requirements |
| Gas tightness | 8.68 m ³ / (m ² • h),national standard level 3 |
| Door Configuration: | With Clear window or small sectional door or without window/door |
| Door Panel Size | Max 12000MM |
| Opening Size | Max 8000MM |
| Heat Transfer | K=0.4-0.5W/㎡K
|
| Opening Speed: | about 130mm/S |
| Operation Counts | Max 100times /24 hours |
| Balance System | External torsion spring balance system, the working life of the torsion spring reaches 400000-800000s working cycle |
| Opening Type: | Button,rope control,remote control,Geomagnetic Control,Photocell Control, Radar Control |
